LA 150-P, C/L Hall Effect Current Sensor, 150 Amp, 75mA Output, PCB Mount, /-12..15V Supply, PCB Mount, X = 0.45%
LA 150-P, C/L Hall Effect Current Sensor, 150 Amp, 75mA Output, PCB Mount, /-12..15V Supply, PCB Mount, X = 0.45%
  • LA 150-P, C/L Hall Effect Current Sensor, 150 Amp, 75mA Output, PCB Mount, /-12..15V Supply, PCB Mount, X = 0.45%
Product Details ＋

LEM LA 150-P Closed Loop AC/DC Hall Effect Sensor

Features

  • Bandwidth DC to 150kHz
  • Closed loop transducer using Hall effect
  • Compact and versatile
  • PCB Mounted with Strain Relief
  • Insulated plastic case recognized according to UL 94-V0

Advantages

  • Very good linearity
  • High accuracy
  • Low temperature drift
  • Wide frequency bandwidth
  • Very low insertion losses
  • High immunity to external interference
  • Current overload capability
  • Low power consumption

Applications

  • AC variable speed drives and servo motor drives
  • Static converters for DC motor drives
  • Battery supplied applications
  • Uninterruptible Power Supplies (UPS)
  • Switched Mode Power Supplies (SMPS)
  • Power supplies for welding applications
  • Water Treatment Electronics
Specification
LEM Part Number LA150-P
Technology Closed Loop Hall Effect
Aperture 13 x 8mm
ROHS Yes
Supply Voltage /-12..15 VDC Bipolar, Isolated
Load Current (RMS DC) 106 Amp (150 Amp DC)
Measurement Range /-200 Amp
Output 53mA (75mA for 150 Amp DC)
Isolation 2.5 kV
Bandwidth DC-150 kHz
Mounting Style PCB Mount
Operating Temperature Range -10°C / 80°C
Accuracy 1%
Termination Style Through Hole PCB
Unit Weight 35g
Factory Pack Quantity 25

Datasheet
Application Notes

LA 150-P, C/L Hall Effect Current Sensor, 150 Amp, 75mA Output, PCB Mount, /-12..15V Supply, PCB Mount, X = 0.45%
  • DefaultTitle

$ 0.00

$ 66.45
