Product Details
＋
LEM LAH 25-NP, Multi Range C/L Current Sensor, Multi Range 25 Amp, 25mA Out, PCB Mount, /-12..15V, X = 0.25% PCB Mount
Features
- Bandwidth DC to 200kHz
- Multi Range through pin selection
- Closed loop transducer using Hall effect
- Compact and versatile
- PCB Mount
- Insulated plastic case recognized according to UL 94-V0
Advantages
- Very good linearity
- High accuracy
- Low temperature drift
- Wide frequency bandwidth
- Very low insertion losses
- High immunity to external interference
- Current overload capability
- Low power consumption
Applications
- AC variable speed drives and servo motor drives
- Static converters for DC motor drives
- Battery supplied applications
- Uninterruptible Power Supplies (UPS)
- Switched Mode Power Supplies (SMPS)
- Power supplies for welding applications
- Water Treatment Electronics
Specification
| LEM Part Number | LAH 25-NP |
| Technology | Closed Loop Hall Effect |
| Aperture | No Aperture |
| ROHS | Yes |
| Supply Voltage | /-12..15 VDC Bipolar, Isolated |
| Load Current (RMS DC) | 8,12,25 Amp Multirange through pin selection |
| Measurement Range | /-55 Amp |
| Output | 25 mA |
| Isolation | 5 kV |
| Bandwidth | DC-200 kHz |
| Mounting Style | PCB Mount |
| Operating Temperature Range | -40°C / 85°C |
| Accuracy | 0.3% |
| Termination Style | Through Hole PCB |
| Unit Weight | 20g |
| Factory Pack Quantity | 25 |
